Summary
Emergency self-latching red push button control with internal key release.
Operation
Spring loaded button latches "in" when pushed, changing contact mode status. Cylinder rotated 45°.
Turning key to 12 O' Clock position releases button which springs out, returning contacts to normal mode status.Product Features
- Red push Button with internal key release
- Custom Engraving Available
- All manufactured with rust resistant 1/4" aluminum
- Non-binding internal stainless steel screws
- Tested for 1,000,000 cycles
Product Specifications
- Plate: 4.50” x 2.75“
- Contact Rating: 6 Amps @ 125VAC/28VDC
- SPDT - Momentary switch (Standard)
- Material: 5052 Marine-type aluminum
- Finish: Clear satin anodized aluminum (Standard)
Finishes
SB: Sandblast RD: Red CU: Custom Finish CA: Clear Anodized DB: Dark Brown WH: Off White NOTE: Engraving Available in Spanish, Japanese, French, Arabic, Portuguese and Chinese. Contact us for details. 718-401-4006 contact@deltrexusa.comSwitch Types
SPDT: Momentary DPDT: Double pull double throw Momentary PNUM: Pnuematic Time-Delay Switch WILS: Wireless TIMR: Dual-timerEngraving Color
RD: Red BK: Black GD: Gold WH: White CU: Custom ColorEngraving Options
E00: No Engraving E01: Exit E02: Push to Exit E03: Push to Open E04: Emergency E07: Push for Help E08: Push to Lock E09: Push to Unlock Gate E11: Push to Sound Alarm E15: Emergency Door Release E22: Push to Exit w/ HCP Logo E24: Push to Open Door w/ HCP Logo E32: Push to Operate Door w/ HCP Logo E41: Request to Exit EH2: HCP Logo ECE: Custom Engraving
